Truck/Trailer Mounted Workover Rig

Truck/Trailer Mounted Workover Rig

Description

Katwell supplied truck/trailer mounted workover rig is mechanically and hydraulically driven. The power system, drawworks, mast, travelling system and transmission mechanism of the workover rig are mounted on the self-propelled chassis, which improves the moving efficiency greatly. Now, Katwell truck mounted workover rig series cover the workover depth from 2000m to 9000m and drawworks power from 250HP to 1000HP, featuring high operation load, reliable performance, excellent off-road performance, convenient movement and low operation/moving cost. Besides, workover rigs for arctic, desert and highland applications are available.

Features

  • Conform to API Q1, 4F, 7K and 8C Specification and API monogrammed.

  • The technical parameters and overall design conform to GB/T 23505 Petroleum Drilling and Workover Rigs.

  • Conduct strength analysis for the mast and substructure.

  • Modular design achieves fast move and transportation.

  • Mechanical transmission, simple operation and easy maintenance.

  • Special off-road chassis extends service life.

Specifications

Model

XJ700Z(T)

XJ900Z(T)

XJ1100Z(T)

XJ1350Z(T)

XJ1600Z(T)

XJ1800CZ(T)

XJ2250CZ(T)

Max.Hook Load

kN(lb)

700

(160000)

900

(200000)

1100

(250000)

1350

(300000)

1600

(360000)

1800

(400000)

2250

(500000)

Rated Hook Load

kN(lb)

400

(90000)

600

(130000)

800

(180000)

1000

(225000)

1200

(270000)

1500

(337000)

1800

(400000)

Nominal

Workover

Depth

m(ft)

Workover

73mm (2 7/8")

Tubing

3200

(10500)

4000

(13100)

5500

(18000)

7000

(23000)

8500

(27900)

Workover

73mm (2 7/8")

Drill Pipe

2000

(6560)

3200

(10500)

4500

(14800)

5800

(19000)

7000

(23000)

8000

(26200)

9000

(29500)

Engine Power kW(hp)

224

(300)

280

(375)

403

(540)

403

(540)

470

(630)

2×403

(2×540)

2×470

(2×630)

Drawworks Rated

Power kW(hp)

185

(250)

260

(350)

335

(450)

410

(550)

485

(650)

560

(750)

745

(1000)

Main Brake

Belt Brake

Belt Brake

or Disc

Brake

Belt Brake

or Disc

Brake

Belt Brake

or Disc

Brake

Belt Brake

or Disc

Brake

Belt Brake or

Disc Brake

Belt Brake or

Disc Brake

Lines of   Travelling

System

6

6

8

8

8

10

10

Drilling Line   Dia.

mm(in)

22

(7/8)

26

(1)

26

(1)

29

(1 1/8)

29

(1 1/8)

32

(1 1/4)

32

(1 1/4)

Travelling   System

Sheave OD mm(in)

610

(24)

760

(30)

760

(30)

760

(30)

760

(30)

915

(36)

915

(36)

Mast Height m(ft)

22(

72)

32

(105)

33

(108)

33

(108)

35

(115)

38

(125)

38

(125)

Self-propelled   Chassis

6×6

8×8 or s10×8

10×8

10×8

12×8

14×8

14×10

Trailer

3-axis

3-axis

3-axis

4-axis

5-axis

5-axis

Remarks

C-Dual-engine   gear compound transmission;Z-Self-propelled   chassis;T-Trailer
